These are the most commonly used models of elements used in these Toasters:
- MM14 and QT14
- Model Number 198002, 500 watts, 208 volts, 18.0 T-T. Our part number 50770
- Model Number 198010, 450 watts, 208 volts, 18.0 T-T. Our part number 50771
- Model Number 197991, 800 watts, 208 volts, 18.0 T-T. Our part number 50772
- Model Number 197988, 550 watts, 208 volts, 18.0 T-T. Our part number 50773
- Model Number 198078, 375 watts, 208 volts, 18.0 T-T. Our part number 50774
- Model Number 198077, 675 watts, 208 volts, 18.0 T-T. Our part number 50775
- QT14B and QT14BR
- Model Number 198102, 675 watts, 208 volts, 18.0 T-T. Our part number 51026
- Model Number 198103, 375 watts, 208 volts, 18.0 T-T. Our part number 51027
- Model Number 198104, 675 watts, 240 volts, 18.0 T-T. Our part number 50984
- Model Number 198105, 375 watts, 240 volts, 18.0 T-T. Our part number 51028
- Model Number 198106, 675 watts, 220 volts, 18.0 T-T. Our part number 51029
- Model Number 198107, 375 watts, 220 volts, 18.0 T-T. Our part number 51030
These are not all the possible models that could be used. This list was derived by analysis of the most used models, and in that process it was found that there are other configurations of conveyor toasters which use different elements. Holman/Star lists more than 42 different elements for the MM14, QM14, QT14 and QT14B models, and there are some conflicting specifications in the equipment manuals. Most units are wired for 208 volt operation, but the elements may be designed for 104 volts. This is normal. Depending on the power available in some areas, units may be wired for 220 or 240 volts. These units may use 110 or 120 volt elements.
We have made every effort to ensure that the models listed above are accurate. You can find Holman/Star manuals here, and their technical support pages here.
To get your 20 percent discount on your order, use coupon code QB20 during checkout. Don't forget that your order must be over $100 to qualify the discount. Click here to go directly to the Holman element ordering page. Scroll down the page about half way to find them.
If you don't see the elements your system uses, please feel free to contact us for further details. We can make them to fit your application at no additional charge.
|
 |
